Polyether outsole marine fender shock absorption material
Get Latest PricePayment Type: | L/C,T/T |
Incoterm: | FOB,CIF |
Min. Order: | 1000 Kilogram |
Transportation: | Ocean,Land,Air |
Port: | Shanghai |
Payment Type: | L/C,T/T |
Incoterm: | FOB,CIF |
Min. Order: | 1000 Kilogram |
Transportation: | Ocean,Land,Air |
Port: | Shanghai |
Model No.: XC-1065G,XC-5009
Brand: Xuchuan Chemical
Place Of Origin: China
Types Of: Synthetic Resin And Plastics
Characteristic: Good hydrolysis resistance and high strength
Application: Marine fender, shock absorption mat and polyether outsole
Appearance: Liquid
Code: XC-1065G,XC-5009
Brand: Xuchuan
Characteristic:Good hydrolysis resistance and high strength
Application:Marine fender, shock absorption mat and polyether outsole
Typical properties of PU matrix
Name of products | Appearance | Viscoscity (mPa·s/40℃) | Density (g·cm-³/40℃) | Package (kg) |
A-1065G | Cream white liqud | 400-800 | 1.01-1.02 | 18 |
B-5009 | Yellowish Transparent liquid | 300-600 | 1.08-1.2 | 20 |
Materials preheat
A-1065G:preheated at 50℃~60℃ for 2~4 hours
B-5009:preheated at 60℃~70℃ for 8~10 hours
Typical processing parameters & Reaction parameter
Items | A/B Materials Temperatures(℃) | Mix ratio A+C+30H2O/B (By weight) | Cream Time (s) | End of Rise Time (s) | Free Rise Foam Density (g/cm³) | Mold Temperature (℃) | Demold Time (min) |
Parameter | 30-35/35-40 | 100/108-110 | 8-10 | 60-70 | 0.25-0.35 | 35-45 | 7-9 |
The adding content of C-2 should be 350±10g/18kg
The adding content of water should be changed according to the reality
Physical properties
Items | Molded Density (g/cm³) | Hardness (Shore C) | Tensile strength (Mpa) | Elongation (%) | Tear Strength (kN/m) | DIN abrasion (mm³) | Hydrolysis 168h, 70℃, 95%r.h.strength retention (%) |
Physical properties | 0.50-0.70 | 65-80 | 3.5-5.5 | 380-450 | 17-22 | 270-350 | >95 |
Demold time may be prolonged with the increse of sole thickness
These physical data are acquired by testing a sample of 6mm thick
Data listed above are just for reference.The data are subjected to practical production.If other requests for physical properties,please contact us.
Xuchuan chemical established in 2007, company registered capital is RMB 500 million. The main products are all ranges polyester polyol, polyurethane resin for shoes, water-based and solvent-free polyurethane resins for artificial leather, polyurethane bonding adhesives and polyurethane hot melt adhesives.
Now Xuchuan has 4 modern production bases, production capacity reached 630,000 tons per year, products exported to 32 countries and regions in the world.
